UNDERSTANDING THE MODEL-GLUE EVENT LIFECYCLE

The Model-Glue framework can present an intimidating learning curve when coming directly out of the procedural world to that of Object Oriented Programming. One of the things that will help the Model-Glue student immensely is to have a solid understanding of how the Model-Glue event lifecycle works: being able to visualize the invisible. With this knowledge in pocket, many of the architectural questions that will inevitably arise will be more easily addressed. So, let’s explore what we mean by the term ‘lifecycle’, what the definition of ‘event’ is in a Model-Glue context, and what Event’s role is in a Model-Glue application!

 A Lifecycle You Already Understand

 Let’s look at a lifecycle you’re already familiar with: http request. Pictures are worth a thousand words, so allow me to illustrate this:

Looks familiar, doesn’t it? The request begins life when the client initiates it with an http call to our web server for a specific template. The server receives the request, grabs the template requested, and hands it over to the Coldfusion server for processing. The Coldfusion server renders the CFM template into pure HTML (since that’s all a browser understands), hands the HTML back to the web server, and the web server returns the HTML to the client. End of the request’s lifecycle!


When a client makes a request of a Model-Glue application, a similar process takes place. The focus of this post will begin (and end) at the point where index.cfm is requested and passed a parameter called “event” (eg; http://www.myMGapp.com/index.cfm?event=home). The receipt of this parameter is the first breath our Model-Glue application draws, and begins the internal process which we will now follow through to its conclusion.

What Exactly IS A Model-Glue Event?

‘Event’ is two distinct things:

• ‘Event’ is a simple value: a name, such as ‘home’, or ‘do.login’ (yes, compound event names are acceptable and even advantageous for organization’s sake!);
• ‘Event’ is a bucket.


 “A bucket?”, you may be asking yourself. Yes, a bucket! Buckets carry things around, and at a certain point in our event lifecycle study we will see how the event changes from being simply a name to an actual value-carrying OBJECT that gets passed around within the application! It’s a beautiful metamorphosis, as you will see.

 The Event Lifecycle in a Nutshell

Let’s begin with an overview of what takes place in the lifecycle of a Model-Glue event (We’ll be exploring each step in detail later):

1. A request is made, notifying model-glue to execute a specific event (eg; http://www.myMGapp.com/index.cfm?event=do.login). At this point, Model-Glue generates an empty Event Object (aka: bucket).
2. Model-Glue looks in its modelglue.xml file to find out what messages to broadcast to listening controllers ( <broadcast><message name="login" /></broadcast> ) for the 'do.login' event.
3. Controllers listening for the "login" message execute their corresponding functions ( <controller name="AuthenticationController" type="controller.AuthenticationController"><message-listener message="login" function="AuthenticateUser" /></controller> ).
4. Model-Glue executes any relevant result actions (behaves as an 'if' statement), if present.
5. Model-Glue renders any views that are defined for this event. HTML is delivered and the event lifecycle is over.


Event Lifecycle, Step One: Create the Event Object (aka: bucket)


The whole event lifecycle depends upon values being passed around within the application, so the first thing Model-Glue does after being notified which event to execute is to create an Event Object. Just visualize it as a bucket at this point.

 After the Event object is created, any incoming form fields and URL parameters are immediately stuffed into it for safekeeping.


Event Lifecycle, Step Two: Reading the Event Definition

 Now that Model-Glue has the Event Object all populated with incoming values, it’s time to discover exactly what should be done with them for the event name that was called. The instructions, or event definitions, that Model-Glue refers to when an event name is received all live in an XML document called “Modelglue.xml”. Here is what an event definition looks like:


Summary of steps 1 and 2

The <event-handler> tag has three children: <broadcasts>, <views>, and <results>, and they are evaluated in that order. Let’s look at each one more closely, following our Event Object through the process.

Event Lifecycle, Step Three: Giving Shout-Outs (aka: making broadcasts)

 The first thing Model-Glue does for a given event is to make any defined broadcast. A broadcast is simply a shout out that triggers certain CFCs to execute specific methods. In our example, the broadcast “login” is made. Model-Glue looks in another section of its Modelglue.XML file to find out what CFCs are “listening” for that particular message, then executes the relevant method. In this scenario, this is what Model-Glue found in it’s XML file:


Ah, so Model-Glue is going to invoke the “Login” method of the AuthenticationController.cfc (which lives in the “controller” directory). Here is an important thing to know at this point: for every method that Model-Glue calls, the Event Object that was initially created and populated will be passed in as an argument, like so:


Why? So that our methods can read values out of it (such as the username and password that were passed in via our login form) AND so our methods can put values INTO the bucket as well! In our example, the Login method is going to attempt to authenticate a user. If it succeeds, it’s going to add a ‘Success’ result to the Event bucket; if authentication fails, it’s going to add a ‘Failure’ result.

Summary of Step 3

Okay, the “Login” method finished, Model-Glue has the Event Object in hand, and there are no more broadcasts defined for this event, so let’s go on to the next step in the Lifecycle.

Event Lifecycle, Step Four: Decide What Results to Execute

 Take a look at the <results> section of the event definition. We see two named results defined (so called because each of them has been given a specific name): success and failure. Recall how our Login method added one of two possible results to the event bucket, either “Success” or “Failure”. At this point, Model-Glue looks for any results in the Event bucket and executes whichever one is appropriate. Executing a result really just means “hey Model-Glue, you found a result named “Success”, eh? Then I want you to jump to the defined event named “home” and execute that now.” If a result named “Failure” had been found, then the “login” event would have been called, presenting the user with the login form again. When Model-Glue executes a named result and jumps to another event, the programmer has two choices at this juncture. To start the new event fresh with an empty Event object, or to carry the existing, populated Object over to the next event. This is controlled with the <result> attribute “redirect”. If set to ‘True’, a new, empty Event object is created; if set to “False’, the original Event Object is passed along.

Summary of Step 4

At this point, all of our messages have been broadcast and relevant methods executed; if we needed to redirect to another event, that was also already accomplished. We’ve now arrived at the final step in the event lifecycle: Render our HTML and send it back!

Event Lifecycle, Step Five: Render The Views!

(aka: create the HTML that will be passed back)

 Since our “do.login” event was all about actions and not views, let’s look at the “home” event that a successful login attempt redirects us to:

 This particular event doesn’t ask Model-Glue to make any broadcasts nor does it ask Model-Glue to look for and process any results. What it DOES do, however, is ask Model-Glue to render two different CFM templates, dspMainContent.cfm and dspLayout.cfm. There are several important things to note here.

 First, that we can tell Model-Glue to render any number of individual CFM templates. Second, notice how each template is given a “name” attribute…the rendered HTML will later be referred to by this name. Third, the order we list them in is irrelevant with one WHOPPING exception: the last template rendered is the ONLY one that Model-Glue will return to the browser. So what happens to the other Views that were rendered and placed onto the Viewstack (notice how I just increased your Model-Glue vocabulary ;) )? All other rendered templates are “included” in the final template, in nearly EXACTLY the same manner as using a CFINCLUDE, only slightly different. See a previous post I did on Views called “Model-Glue Views Demystified” for more detailed information on this topic. Now, let’s find out where our Event Object/Bucket is relative to the views that are being rendered, shall we?

 Model-Glue makes the contents of the Event Object available to your CFM view templates in an object referred to as “ViewState”. It, too, is an object, very similar to the Event Object, and it contains all the values that your template could possibly need. You may be asking yourself, “why do we need the ViewState Object if we already have a perfectly good Event Object?”. Valid question, and the answer lies within the philosophy of object oriented programming and the two cardinal virtues that a framework like Model-Glue seeks to uphold: Encapsulation and Autonomy. Suffice it to say that in order not to violate basic MVC principles, copying the contents of the Event Object into the ViewState Object was the better thing to do. Okay, take a look at the following two lines of code taken from within a view template:

 Any CFM template created for use within a Model-Glue application can absolutely count on the presence of “ViewState”. The value “firstname” that we’re retrieving from ViewState is a value that was placed in the Event Bucket at some point previously in the event lifecycle, likely by one of our broadcasts. Are you seeing the beauty of the Event Object yet? From the beginning of our event call, that bucket was passed around here and there, values being put into it, redirections being made as needed, until finally we arrive at our views where all of the previously saved values are made available for use within your templates. Strings, Arrays, Structures, Queries, and even other Objects can be stuffed into the Event Bucket and made available via ViewState. No limitations in that arena!

Slightly off topic from this article, let’s quench some curiosity and sneak a quick peek at how the final view being rendered includes content previously rendered in the viewstack, in this case, how “body” is output within “final”. Take a gander at the following few lines of code:

Yes, it’s really that simple. All rendered views are placed onto the viewstack, referenced by the name we gave them in the event definition, and are available within our template by accessing the “ViewCollection”.  Again, for more detail on Model-Glue views, see the “Model-Glue Views Demystified” post.

Views all rendered and the final HTML complete, Model-Glue returns it to the web server, which in turn returns it to the browser that requested this particular event in the first place.

Summary of Step 5, and the end of our Event Lifecycle

This is the end of our Event’s life; it is disposed of properly. RIP.


One Final Bit of Trivia

If you’re curious about what the Event Object really looks like, here’s a CFDUMP showing it and its methods:

CFDUMP of the Event Object

Conclusion

 As its name implies, Model-Glue is a framework that allows a developer to create code that is truly self-contained and reusable by acting as the glue that binds all the pieces together. It accomplishes this by managing the one common denominator that the Model, View, and Controller all have in common: The Event Object. From the client’s initial call to the final delivery of the requested HTML to the browser, it is the Event Object that the developer must understand and interact with in order to create a working application. Only a mid-level understanding of the event lifecycle is required to meet the majority of architectural needs. How to incorporate security, how to ensure the display of appropriate navigation, how to easily add in new functionality: these are all common challenges that understanding the Model-Glue event lifecycle will enable any developer to overcome.
